Harvia
Harvia Vega BC23 Electric Sauna Heater 2.3 kW
HCB230400S, Vega Compact, 1.3-2.5 m³
Delivery time approx. 2–4 weeks
Electrical connection in Norway
The heater can be connected to 230 V 1N~.
Single-phase connection on a dedicated circuit.
Before buying, check with your electrician how much power can be supplied to the heater from the distribution board.
The heater is intended for fixed installation and must only be installed by a registered electrical contractor. The electrician needs both the heater power and the fuse requirement for the chosen voltage.
Fuse and cable cross-section, 2,3 kW
| Fuse | Cable | |
|---|---|---|
| 230 V 1~ | 10 A | 1,5 mm² |
Source: Harvia. Indicative – the electrician sizes according to NEK 400.
Harvia Vega BC23 Electric Sauna Heater 2.3 kW, HCB230400S, Vega Compact, 1.3-2.5 m³
The Harvia Vega Compact is a user-friendly electric heater designed for small saunas. Its control switches are positioned at the top for optimal ergonomics. The heater is easy to install using a single mounting bracket and can be positioned low on the wall, allowing heat to reach the lower benches. The unit is made of stainless steel.
Modern ease of use
-Small and compact wall-mounted heater
-Can be installed low for better heat distribution
-Control switches located at the top of the unit
Height: 505 mm
Width: 280 mm
Depth: 295 mm
Stone size: Ø5–10 cm
SKU: 6417659010375
